0.05mm silver-plated stranded copper wire multi-layer plating

DescriptionItemStandard diameter (mm)0.05≤d≤0.090.09<d≤0.250.25<d≤0.5Tolerance (mm)±0.003±0.004±0.005Resistance (Ωmm²)≤0.01851≤0.01802≤0.0177Elongation (%)*≥6≥12≥15       Number of stranded wires*       7-100Directionright
send email to us

Featured Products


0.05mm Silver Plated Stranded Copper Wire Multilayer Plated0.05mm Silver Plated Stranded Copper Wire Multilayer Plated0.05mm Silver Plated Stranded Copper Wire Multilayer Plated

0.05mm Silver Plated Stranded Copper Wire Multilayer Plated

Description

ItemStandard diameter (mm)
0.05≤d≤0.090.09<d≤0.250.25<d≤0.5
Tolerance (mm)±0.003±0.004±0.005
Resistance (Ωmm²)≤0.01851≤0.01802≤0.0177
Elongation (%)*≥6≥12≥15
       Number of stranded wires*       7-100
Directionright S or left Z
Pitch (mm)*2.0-100 mm
Tensile strength (Mpa)≥196
Plating layer (um)*0.3-2.0 um
ExteriorNo scratches, oil stains, copper exposure, oxidation, etc.
Packaging*                                    type 200/300/400 plastic reel; type 400/500 iron reel, etc.
NoteCustomization Available
